Features
Fuel Tank
Large capacity with 7 liters. Suitable for long distance rides
30mm Throttle Body
Larger throttle body to boost overall performance, increase engine power and torque
Adjustable Brake/Clutch Alloy Lever
Better suit for different situation
Analog Digital Display
Stylish design with combination of comprehensive information (Engine Oil Check, Engine Temperature, Clock Battery Power, Anti Lock Braking System (ABS))
DRL
Bright LED Light. Easy to be seen at any condition
Engine
SOHC, 4 stroke, Liquid cooled, Single Cylinder & 185cc
Rear Lamp
Striking LED Rear Lamp with maximum emitting power
Back Seat (Grab Bar)
Specially designed grab bar for ride pillion
ASSESSMENT ICONS
MyMAP uses four recognizable icons to refer to its four main pillars of assessment –Compliance to United Nation Regulations , Conformity of Production, Safety Technology and Support Programme.
Specification
Engine
- TYPE SOHC, 4 stroke, Liquid-cooled, Single Cylinder
- BORE X STROKE 63.5 x 57.8 mm
- DISPLACEMENT 183 c.c.
- MAX POWER 14.7 kW at 9,000 r/min
- MAX TORQUE 17.4 Nm at 7,500 r/min
- COMPRESSION RATIO 11.1:1
- FUEL SYSTEM Electronic Fuel Injection
- TRANSMISSION 6 - Speed
- LUBRICATION SYSTEM Forced Circulation and Splashing
- CLUTCH TYPE Wet Multi Disc Clutch
- STARTER Electric
- IGNITION Full Transistor Ignition
Specifications change without prior notice
Chassis
- FRONT SUSPENSION Telescopic Forks
- REAR SUSPENSION Telescopic Coil
- FRONT BRAKE Single 250 mm disc ABS
- REAR BRAKE Single 200 mm disc
- FRONT TYRE 90/80- 17 (Tubeless)
- REAR TYRE 120/70-17 (Tubeless)
- DRY WEIGHT (kg) 124
- SEAT HEIGHT (mm) 790
- WHEELBASE (mm) 1,290
- GROUND CLEARANCE (mm) 150
- FUEL CAPACITY (Liter) 7
- BATTERY 12V7Ah (Maintenance Free – MF)
Specifications change without prior notice
